The Pinarello Dogma F is the ultimate road racing machine, engineered for those who demand the highest level of performance, precision, and speed.

The Pinarello Dogma F is the ultimate road racing machine, engineered for those who demand the highest level of performance, precision, and speed.

Pinarello

Pinarello Dogma F - Dura-Ace Di2 equipped Road Race bike - Luxter Blue

£12,600.00
Earn
in Customer Rewards when you buy this item today
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined
Earn Rewards
When you purchase this item, you will earn of rewards points to spend on your next purchase from us. You can spend your Rewards balance in-store & online.

Pinarello Dogma F - Dura-Ace Di2 equipped Road Race bike - Luxter Blue

Season:2025

Brand:Pinarello

Code:C1969277159-306SHIM

The Pinarello Dogma F is the ultimate road racing machine, engineered for those who demand the highest level of performance, precision, and speed. Combining advanced aerodynamics, cutting-edge technology, and lightweight carbon construction, the Dogma F is built to dominate the competition.

Ultra-Lightweight Carbon Frame for Maximum Efficiency

Crafted from TorayCa T1100 1K Dream Carbon, the Dogma F offers an exceptional balance of stiffness, responsiveness, and comfort. Its asymmetric frame design enhances power transfer, ensuring that every pedal stroke delivers maximum efficiency and speed. Aerodynamic refinements further reduce drag, making the Dogma F the ultimate race-ready road bike.

Shimano Dura-Ace Di2 12-Speed Groupset

Equipped with the Shimano Dura-Ace Di2 12-speed electronic groupset, the Dogma F delivers lightning-fast, precise shifting. This cutting-edge drivetrain ensures smooth and reliable gear changes, allowing riders to maintain peak performance in every racing scenario.

DT Swiss ARC 1400 Wheels for Superior Speed

The DT Swiss ARC 1400 wheels provide exceptional aerodynamics and responsiveness, optimizing speed and efficiency on the road. Engineered for race-winning performance, these wheels deliver outstanding stability and control at high speeds.

MOST Finishing Kit for Premium Comfort & Control

The Dogma F features a MOST finishing kit, including high-performance handlebars, stem, and seatpost, designed to enhance ergonomics and riding comfort. This premium cockpit setup ensures optimal aerodynamics and control for elite-level racing and long-distance riding.

Striking Color Options

The Pinarello Dogma F is available in two exclusive and luxurious finishes:

  • Luxter Red Gold – A bold and striking colorway that exudes speed and sophistication.
  • Luxter Blue – A deep, elegant shade that blends performance with refined aesthetics.

Why Choose the Pinarello Dogma F?

For cyclists who demand nothing but the best, the Dogma F is the perfect fusion of aerodynamics, lightweight performance, and race-winning technology. Whether you're sprinting for the finish line or conquering the toughest climbs, this bike is engineered to elevate your ride to the next level.

Experience the pinnacle of road cycling with the Pinarello Dogma F – designed for champions, built for victory.

Pinarello MyWay

Looking for something a bit different? Pinarello’s MyWay program allows riders to customize the Dogma F and Dogma X bikes with a personalized color scheme. Through a simple four-step process, cyclists can choose from five graphic layouts (mono, faded, cut, edge and xolar), 27 colours, five decal styles, and matte or glossy finishes, resulting in thousands of unique combinations.

Technical Information
  • Frame
  • Sizes
    430mm, 460 mm, 500 mm, 515mm, 530 mm, 540mm, 550 mm, 560mm, 575 mm, 595mm, 620 mm
  • Colours
    Luxter Red Gold or Luxter Blue
  • Frame
    TorayCa M40X, TiCR™ Cable Routing, Italian BB
  • Forks and Shocks
  • Fork
    NEW eTICR Onda Fork with ForkFlap™, 1.5' upper and lower steerer
  • Rear Shock
    N/A
  • eSystem
  • Motor
    N/A
  • Controller
    N/A
  • Display
    N/A
  • Battery Type
    N/A
  • Battery Integration
    N/A
  • Connectivity
    N/A
  • Charger
    N/A
  • Drivetrain and Brakes
  • Brake System
    Dura Ace BR-R9200, 2 pistons caliper (160mm / 140mm)
  • Rear Derailleur
    Shimano Dura Ace Di2 RD-R9200 12s
  • Front Derailleur
    Shimano Dura Ace Di2 FD-9200 12S
  • Shifters
    Dura Ace BR-R9200
  • Bottom Bracket
    Shimano Dura Ace SM-BB9200
  • Crankset
    Shimano Dura Ace FC-R9200, HollowTech 2, 12s
  • 170mm Crank length
    430 mm, 460 mm, 500 mm, 515 mm frame sizes
  • 172.5mm Crank length
    530 mm, 540 mm, 550 mm, 560 mm frame sizes
  • 175mm Crank length
    575 mm, 595 mm, 620 mm frame sizes
  • Cassette
    Shimano Dura Ace CS-R9200 12S
  • Chain
    Shimano Dura Ace CN-HG 12S
  • Cockpit
  • Handlebar
    MOST Ultrafast
  • Stem
    Integrated into handlebars
  • Grips
    MOST bar tape
  • Headset
  • Wheels
  • Wheelset
    DT Swiss ARC 1400
  • Front Tyre
    Continental Gran Prix 5000S TR28-622
  • Rear Tyre
    Continental Gran Prix 5000S TR28-622
  • Max Tyre Clearance
  • Finishing Kit
  • Seatpost
    Pinarello Aero seatpost with 3D printed titanium top seatclamp and bolts
  • Saddle
    Pinarello Lynx Ultra Superflow
  • Pedals
    Not supplied: Shop pedals here
  • Extras
  • Kickstand
    N/A
  • Lighting
    N/A
  • Lock
    N/A
  • Carrier
    N/A
  • Mudguards
    N/A
  • Extras
    N/A
  • Please Note:
    Every effort has been made to ensure accuracy throughout this website. However, manufacturers reserves the right to change bike specifications, features, prices and colours without prior notice. If you would like to check the specification of a bike before purchasing, please call one of our stores.
Sizing Information

Size Guide

The choice of an exact frame size is a very complex and delicate topic which is not always straightforward without seeing an athlete on his/her bike. In addition to this, Pinarello offers a wide range of frame options and components that offer both very accurate position options but also require in-depth evaluations.

In addition to this, as more and more bikes are beginning to be fitted with an integrated handlebar and stem setup it is even more important to discuss sizing with us. Getting this measurement wrong can result in an incorrect position on the bike and an incur an expensive cost when having to replace the handlebar / stem combo for a correctly sized version.

If you have any questions specific to sizing, call our Cramlington store and speak with our bike fitter who will be able to help with an initial sizing before purchasing your bike. Once purchased we are happy to supply a full bike fit when you collect your new Pinarello from in store.

Get in touch with one of our stores (Newcastle - 0191 276 0941 or Cramlington - 01670 712 536) to find out how we can help.

Frame Geometry


430

465

500

515

530

540

550

560

575

595

620

ASeat Tube Length (mm)

430

465

500

515

530

540

550

560

575

595

620

BSeat Tube Angle74.4°74.4°74°73.7°73.7°73.4°73.4°73°73°72.472°
CTop Tube Length (mm)500515525535545550557565575587620
DHead Tube Length (mm)102109114119128136147154.5168204244
EHead Tube Angle69.5°70.5°71.4°72°72.5°72.8°72.8°73.2°73.7°73.4°73.4°
FFork Rake (mm)4747474747474747474747
GTrail (mm)
HWheel Base (mm)
IChain Stay Length (mm)407407407407407408408409409409411
JBottom Bracket Drop (mm)6772727272727272726767
KStack (mm)502517.3525.2532.1542.4551561.5570.1584.8613.2651.6
LReach (mm)351.5365.4372.2378.2383.3385.3389.2390.8396.7393.4410
MStand Over Height (mm)
NHandlebar Width (mm)400420420420420420440440440460460
OStem Length (mm)809090100110110110120120120130
PCrank Length (mm)170170170170172.5172.5172.5172.5175175175
QWheel Size700c700c700c700c700c700c700c700c700c700c700c
Professional Opinion
  • Carbon M40X
    The DOGMA evolves, changing its skin to surprise you one more time. We tested this new carbon fiber lay-up our X-Light models and Ineos Grenadiers team bikes. This new fibre has an exceptional tensile module that allowed us to reach the next level of lateral stiffness performance on the latest generation of our DOGMA F.
  • Downtube
    The downtube has been completely redesigned to reduce the thickness and therefore improve the frontal aerodinamic performance of the frame and the aero drag.
  • Aero-keel BB
    Trickle-down technology from the Hour Record, The new DOGMA F down tube is rotated by 3.5°, to create a keel shape that improves the aero performance of the BB area by 1.2%.
  • Top Tube
    Our unique head tube “nose” shape, introduced first on the DOGMA F8 in 2014, evolves again, reducing the volume and the width of of the nose area by 8mm with a more streamlined design to improve the frontal aero penetration.
  • Headset
    To reduce so much the width of headtube we had to design an innovative elliptical steering tube and a completely new headset with differentiated bearings diameter, wider on the bottom and narrower at the top.
  • Thru Axles
    New shorter thru axles. The bolt on the righ side of the fork has been integrated in the carbon eliminating the external hole. Same has been done also on the frame with the additional integration of the rear derailleur dropout. This solution improves both design and aero performances of the frame.
  • New Onda Fork
    The new slimmer fork design improves aerodynamics, with a 47mm rake, tested with pro rider feedback to improve handling and speed on the descents.
  • Integrated Seat Post Clamp
    Our seatpost clamp has been reduced in size and fully integrated inside the frame seat tube. This new solution reduces the weight, improves the design and increases the cleanliness of the system by limiting the amount of dust and sweat that can access the clamp.
  • NEW Talon Fast
    The new Talon Ultra Fast integrated cockpit is lighter and more aero. It is designed with a natural twisted lever position to allow our riders to find a more aero position in a safe manner.
