Sizes
27.5": XS, S, M 29": S, M, L
Colours
Purple Ash
Frame
ALUXX-Grade Aluminum, 120mm FlexPoint Suspension
Fork
Giant Crest 34 SL RCL, 130mm, 15x110
Shock
Suntour Raidon R, 185/45, custom tuned for Liv
Handlebar
Giant Connect Trail, alloy For 27.5: XS:730mm, S:750mm, M:750mm For 29: S:750mm, M:750mm, L:780mm
Grips
Giant Sole-O
Stem
Giant Contact For 27.5: XS:40mm, S:50mm, M:50mm For 29: S:50mm, M:50mm, L:60mm
Seatpost
Giant Contact Switch dropper, remote For 27.5: XS: 75mm travel / 30.9 x 295mm S: 100mm travel / 30.9 x 345mm M: 125mm travel / 30.9 x 395mm For 29: S: 100mm travel / 30.9 x 345mm M: 125mm travel / 30.9 x 395mm L: 125mm travel / 30.9 x 395mm
Saddle
Liv Sylvia
Pedals
Not included
Shifters
Shimano Deore M4100, 1x10
Front Derailleur
N/A
Rear Derailleur
Shimano Deore M5120
Brakes
Shimano BR-MT420, hydraulic, Shimano RT-26 rotors [F]180mm, [R]160mm
Brake Levers
Shimano BL-MT201
Cassette
Shimano Deore M4100, 11x46
Chain
KMC X-10
Crankset
Praxis Cadet Boost, 30t For 27.5: XS:165mm, S:170mm, M:170mm For 29: S:170mm, M:170mm, L:170m
Bottom Bracket
Praxis, press fit
Rims
For 27.5: Giant AM 27.5, sleeve-joint rim, 30mm inner width For 29: Giant AM 29, sleeve-joint rim, 30mm inner width
Hubs
Giant Boost, sealed
Spokes
Sapim
Tyres
For 27.5: [F] Maxxis Rekon 27.5x2.6 WT, EXO, TR, tubeless [R] Maxxis Ardent Race 27.5x2.6 WT, EXO, TR, tubeless For 29: [F/R] Maxxis Forecaster 29x2.35 WT, EXO, TR, tubeless
Extras
For 27.5: Factory set up tubeless, max tyre size 2.6", max chainring size 32t For 29: Factory set up tubeless, max tyre size 2.4", max chainring size 32t
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
