Sizes
XS and S: MX only M: 29" F&R out of the box, MX compatible
Colours
Mushroom
Frame
Advanced-Grade Composite front and rear triangles, 150mm Maestro Suspension, flip chip – Maestro 3, integrated down tube storage
Fork
Marzocchi Bomber Z1, 160mm, Rail damper, Boost, 15x110, Kabolt, tapered, 44mm offset
Shock
Fox Float DPS Performance 185x55, custom tuned for Liv
Handlebar
Giant Contact SL TR35, 35mm, 20mm rise XS: 760mm, S: 760mm, M: 760mm
Grips
Liv Tactal Pro Single Lock-On XS and S: 110mm, M: 120mm
Stem
Giant Contact SL, 35mm XS: 40mm, S: 50mm, M: 50mm
Seatpost
TranzX travel-adjustable dropper, remote XS: 120-150mm travel / 30.9 x 459mm S: 120-150mm travel / 30.9 x 459mm M: 140-170mm travel / 30.9 x 499mm
Saddle
Liv Sylvia
Pedals
platform
Shifters
SRAM SX Eagle, 1x12
Front Derailleur
N/A
Rear Derailleur
SRAM SX Eagle
Brakes
Tektro M745, hydraulic, Tektro rotors [F]203mm, [R]180mm
Brake Levers
Tektro
Cassette
SRAM SX Eagle, 11x50
Chain
SRAM SX Eagle
Crankset
SRAM SX, 30t, 55mm chainline XS: 165mm, S: 170mm, M: 170mm
Bottom Bracket
SRAM DUB, press fit
Rims
Giant TR 1 29 WheelSystem, alloy, 30mm inner width XS and S: [F] 29", [R] 27.5" M: [F] 29", [R] 29"
Hubs
alloy, sealed bearing
Spokes
Sapim
Tyres
[Size XS, S and M, Front] Maxxis Minion DHF 29x2.5WT, 3C Max Terra, EXO, TR, tubeless [Size XS and S, Rear] Maxxis Dissector 27.5x2.4WT, 3C Max Terra, EXO, TR, tubeless [Size M Rear] Maxxis Dissector 29x2.4WT, 3C Max Terra, EXO, TR, tubeless
Extras
MRP AMg V2 chainguide, 3M tailgate protector, factory tubeless set up, max tire size 2.5", max chainring size 32t, integrated down tube storage bag
