Kemen Tour owns the city streets, designed for speed, comfort, and versatility. Its confident, secure handling and wide range of accessories open up a whole world of possibilities.
Kemen Tour owns the city streets, designed for speed, comfort, and versatility. Its confident, secure handling and wide range of accessories open up a whole world of possibilities.
Orbea

2025 Orbea Kemen Tour 20 - Electric Hybrid Bike - Diamond Black

£3,299.00
Earn
in Customer Rewards when you buy this item today
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined
Earn Rewards
When you purchase this item, you will earn of rewards points to spend on your next purchase from us. You can spend your Rewards balance in-store & online.

2025 Orbea Kemen Tour 20 - Electric Hybrid Bike - Diamond Black

Season:2025

Brand:Orbea

Code:S369TTCCW7

Kemen Tour owns the city streets, designed for speed, comfort, and versatility. Its confident, secure handling and wide range of accessories open up a whole world of possibilities.

The powerful Shimano EP motor and 630Wh battery are perfect for heavy loads and steep roads.

Choose to be free - Whizz through the morning traffic and breathe fresh air on your way to work. Let Kemen take the strain so you don´t break a sweat. After work, take the long way home, escape the bike lane and have an urban adventure.

Features:
  • Smooth the streets - Tthe 80mm fork offers just enough travel to soak up the rougher roads.
  • Powerful Ep6 motor - The powerful ep motor system offers 85nm of assistance for a worry-free commute.
  • You can do this all day - The 630wh battery, integrated into the downtube uses the latest cell technology to pack more charge into a smaller space.
  • Intelligent lighting system - Tvery kemen has a built in, high-tech lighting system which automatically switch on to keep you safe and light the way ahead.
  • 20kg rear rack - The solid and robust rack works with traditional pannier hooks, ortlieb ql 3.1, mik and mik-side mounting systems and can carry up to 20kg.
Technical Information
  • Frame
  • Sizes
    Small, Medium, Large, XL
  • Colours
    Spaceship Green (Matt)
    Ivory White (Gloss)
    Diamond Black (Gloss)
  • Frame
    Orbea Kemen Top Bar, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148x12, carrier and kickstand compatible
  • Forks and Shocks
  • Fork
    SR Suntour Mobie34 80mm Air Q15x110 12x100mm, thread M12x1. Long mudguards compatible.
  • Rear Shock
    N/A
  • eSystem
  • Motor
    Shimano EP600
  • Controller
    EN600-L
  • Display
    N/A
  • Battery Type
    Orbea Internal 540Wh
  • Battery Integration
    N/A
  • Conectivity
    N/A
  • Charger
    Orbea 2.Generation eBike Smart charger 42V/2-4A
  • Drivetrain and Brakes
  • Brake System
    Shimano MT200 Hydraulic Disc
  • Rear Derailleur
    Shimano Cues U4000 GS Shadow
  • Front Derailleur
    N/A
  • Shifters
    Shimano Cues SL-U4000
  • Bottom Bracket
  • Crankset
    Shimano Steps EM600
  • Cassette
    Shimano CS-LG300 11-46t 9-Speed
  • Chain
    KMC eGlide
  • Cockpit
  • Handlebar
    Orbea Urban, Integrated Light, Rise 50, Width 720
  • Stem
  • Grips
  • Headset
  • Wheels
    Alloy, Tubeless, 29", 29c, 32H
  • Front Wheel Axle
  • Front Tyre
    Schwalbe Marathon, 50-622, Reflective Tape
  • Rear Tyre
    Schwalbe Marathon, 50-622, Reflective Tape
  • Max Tyre Clearance
  • Finishing Kit
  • Seatpost
    Alloy, 31.6mm, Setback 0, suspension
  • Saddle
    Selle Royal Vivo Ergo
  • Pedals
  • Extras
  • Kickstand
    Massload rear adjustable
  • Lighting
    Front - Supernova Starstream Pro, High Beam
    Rear - Orbea Fender integrated, with alert light
  • Lock
    N/A
  • Carrier
    Orbea RR-01 Alloy, w/Mik & Mik Side and Ortlieb QL3.1 system. Max. 20Kg
  • Mudguards
    Curana Apollo Orbit 60mm
  • Other
    Bell - Knog OI Classic
  • Please Note:
    Every effort has been made to ensure accuracy throughout this website. However, manufacturers reserves the right to change bike specifications, features, prices and colours without prior notice. If you would like to check the specification of a bike before purchasing, please call one of our stores.
Sizing Information

Size Guide

Frame SizeRider height (cm)
S153 - 172
M164 - 183
L176-195
XL187-206


Frame Geometry


SMLXL
ASeat Tube Length (mm)428442.7457.3472
BSeat Tube Angle74.7°74.7°74.7°74.7°
CTop Tube Length (mm)583.5612641669.5
DHead Tube Length (mm)129.5138.6150.6170.2
EHead Tube Angle66.5°67.2°67.2°67.2°
FFork Rake (mm)46464646
GTrail (mm)
HWheel Base (mm)1162119112221253
IChain Stay Length (mm)450450450450
JBottom Bracket Drop (mm)65656565
KStack (mm)63364465563
LReach (mm)417444.5470.5494
MStand Over Height (mm)
NHandlebar Width (mm)720720720720
OStem Length (mm)
PCrank Length (mm)
QWheel Size29"29"29"29"
Professional Opinion
  • Intergrated Lights
  • Rear Rack fitted
  • Kickstand
