Superlight, ultra-efficient and rides like a dream. This well rounded race bike blends industry leading composite frame engineering with fully integrated components.
Superlight, ultra-efficient and rides like a dream. This well rounded race bike blends industry leading composite frame engineering with fully integrated components.
Giant

2025 Giant TCR Advanced Pro Frameset - Road Race Frameset - Gloss Blue Dragonfly / Brushed Foil

£1,999.00
Earn
in Customer Rewards when you buy this item today
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined
Earn Rewards
When you purchase this item, you will earn of rewards points to spend on your next purchase from us. You can spend your Rewards balance in-store & online.

2025 Giant TCR Advanced Pro Frameset - Road Race Frameset - Gloss Blue Dragonfly / Brushed Foil

Season:2025

Brand:Giant

Code:1913006

Superlight, ultra-efficient and rides like a dream. This well rounded race bike blends industry leading composite frame engineering with fully integrated components to help you climb, corner and descend with astonishing speed and sublime road handling.

SYSTEM OPTIMISATION

The frameset, wheels, cockpit and other parts are engineered, developed and tested together to perform as a system. The all-new OverDrive Aero steerer tube technology is combined with a Contact SL AeroLight stem and Contact SL handlebar to incorporate internal cable routing that integrates the top cap, cables and spacers in a more aerodynamic, user-friendly setup.

WINNING EFFICIENCY

Featuring a greater stiffness-to-weight ratio than the previous generation, along with new aero tube shaping and a lighter overall weight, this uncompromising race bike delivers explosive acceleration and unyielding pedalling stiffness. The result is race-winning performance in the moments that count.

INTEGRATED AERODYNAMICS

All tube shapes are engineered and developed using Computational Fluid Dynamics (CFD) modelling and wind-tunnel testing. From the truncated ellipse shape of frameset tubing to a new cockpit design and component integration, it all adds up to a more streamlined profile that improves overall aero performance compared to the previous generation.

Technical Information
  • Frame
  • Sizes
    X-Small (425mm), Small (445mm), Medium(470mm), Medium / Large (500mm), Large(530mm), X-Large (560mm)
  • Colours
    Gloss Blue Dragonfly/Brushed Foil
  • Frame
    Advanced-Grade Composite 12x142mm thru-axle, Disc
  • Forks and Shocks
  • Fork
    Advanced SL-Grade Composite, Full-Composite OverDrive Aero Steerer, 12x100mm thru-axle, Disc
  • Rear Shock
    N/A
  • eSystem
  • Motor
    N/A
  • Controller
    N/A
  • Display
    N/A
  • Battery Type
    N/A
  • Battery Integration
    N/A
  • Conectivity
    N/A
  • Charger
    N/A
  • Drivetrain and Brakes
  • Brake System
    N/A
  • Rear Derailleur
    N/A
  • Front Derailleur
    N/A
  • Shifters
    N/A
  • Bottom Bracket
    Pressfit 86.5x41mm. Not included
  • Crankset
    N/A
  • Cassette
    N/A
  • Chain
    N/A
  • Cockpit
  • Handlebar
    N/A
  • Stem
    N/A
  • Grips
    N/A
  • Headset
  • Wheels
  • Front Hub
    N/A
  • Rear Hub
    N/A
  • Rim
    N/A
  • Front Tyre
    N/A
  • Rear Tyre
    N/A
  • Max Tyre Clearance
    33mm
  • Finishing Kit
  • Seatpost
    Giant Variant, Composite Offset -5/+15mm
  • Saddle
    N/A
  • Pedals
    N/A
  • Extras
  • Kickstand
    N/A
  • Lighting
    N/A
  • Lock
    N/A
  • Carrier
    N/A
  • Mudguards
    N/A
  • Other
    Headset, spacers, axles, out front computer mount
  • Please Note:
    Every effort has been made to ensure accuracy throughout this website. However, manufacturers reserves the right to change bike specifications, features, prices and colours without prior notice. If you would like to check the specification of a bike before purchasing, please call one of our stores.
Sizing Information

Size Guide

Frame SizeRider height (cm)Rider height (feet)
XS157 - 169
S165 - 175
M171 - 181
M / L177 - 187
L183 - 193
XL189 - 199

Frame Geometry


XSSMM / LLXL
ASeat Tube Length (mm)425445470500530560
BSeat Tube Angle74.5°74.0°73.5°73.0°73.0°72.5°
CTop Tube Length (mm)520535550565580600
DHead Tube Length (mm)120130145165185200
EHead Tube Angle71.0°72.3°73.5°73.0°73.0°72.5°
FFork Rake (mm)454545454545
GTrail (mm)72.064.059.059.059.059.0
HWheel Base (mm)97697798099110061020
IChain Stay Length (mm)405405405405405405
JBottom Bracket Drop (mm)726969676767
KStack (mm)517528545562581596
LReach (mm)376383388393402412
MStand Over Height (mm)703722743771798822
NHandlebar Width (mm)400400420420440440
OStem Length (mm)8090100110110120
PCrank Length (mm)170170172172175175
QWheel Size700c700c700c700c700c700c
Professional Opinion
  • Advanced Composite Technology
    Giant’s High Performance Grade raw carbon material is used to produce this custom frame material in our own composite factory with a high stiffness-to-weight ratio. The front triangle of these framesets is assembled and molded as one continuous piece in a proprietary manufacturing process called Modified Monocoque Construction.
  • Compact Road Design
    Introduced by Giant with the professional Team ONCE in the 1990s, Compact Road revolutionized the look and feel of high-performance road bikes forever. A downward sloping top tube (from the headtube to the seat tube) creates smaller front and rear triangles for a lighter, stiffer bike. It also makes it easier for riders of all sizes to have a perfect fit.
  • OverDrive Aero
    Found inside the head tube of the Defy, Propel and TCR ranges, the D-shaped fork steerer tube and corresponding spacers provide an extremely aerodynamic, easier to service system of internally routed brake and derailleur cables.
  • Powercore
    A massively oversized bottom-bracket / chain stay area features a fully integrated, 86-millimeter wide bottom-bracket design (92-millimeter wide for off-road bikes). Asymmetric chain stays provide additional stiffness on the drive side and stability on the non-drive side.
