The Pinarello X7 Disc road bike in Xpeed Red, equipped with a 12-speed Shimano Ultegra Di2 groupset, is a masterpiece of engineering tailored for endurance cyclists seeking both performance and comfort.
The Pinarello X7 Disc road bike in Xpeed Red, equipped with a 12-speed Shimano Ultegra Di2 groupset, is a masterpiece of engineering tailored for endurance cyclists seeking both performance and comfort.
Pinarello

Pinarello X7 Disc - Ultegra Di2 equipped Endurance Road Bike - Xpeed Red

£7,000.00
Earn
in Customer Rewards when you buy this item today
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined
Earn Rewards
When you purchase this item, you will earn of rewards points to spend on your next purchase from us. You can spend your Rewards balance in-store & online.

Pinarello X7 Disc - Ultegra Di2 equipped Endurance Road Bike - Xpeed Red

Season:2025

Brand:Pinarello

Code:C1888170217-315XR

The Pinarello X7 Disc road bike, available in Xpeed Red or Xpeed Saturn Silver, is a masterpiece of engineering designed for endurance cyclists seeking both performance and comfort. Equipped with the 12-speed Shimano Ultegra Di2 groupset, this bike delivers seamless shifting and top-tier braking performance, making it an excellent choice for long-distance rides.

Frame and Design

Crafted from TorayCa T900 UD carbon fiber, the X7 balances responsiveness and vibration dampening, ensuring a smooth ride. The Endurance+ geometry promotes a more relaxed position, making it ideal for varied road conditions and extended hours in the saddle. X-Stays technology in the rear triangle helps absorb road vibrations while maintaining a lightweight and stiff frame. Additionally, the X7 can accommodate tires up to 35mm, providing enhanced versatility across different

Drivetrain and Braking System

The Shimano Ultegra Di2 12-speed electronic shifting ensures precise and rapid gear changes, enhancing the overall riding experience. Complementing this, Shimano Ultegra hydraulic disc brakes offer exceptional stopping power and modulation, ensuring confidence in all conditions.

Wheelset and Tires

Equipped with the MOST Ultrafast 45 wheelset and Pirelli P7 tires, the X7 delivers efficient rolling and speed, making it perfect for endurance cycling and spirited rides.

Aesthetic Appeals

With a choice of Xpeed Red or Xpeed Saturn Silver, the Pinarello X7 offers sleek lines and a striking finish, reflecting Pinarello’s commitment to both performance and style.

Pinarello MyWay

Looking for something a bit different? Pinarello’s MyWay program allows riders to customize the Dogma F and Dogma X bikes with a personalized color scheme. Through a simple four-step process, cyclists can choose from five graphic layouts (mono, faded, cut, edge and xolar), 27 colours, five decal styles, and matte or glossy finishes, resulting in thousands of unique combinations.

Technical Information
  • Frame
  • Sizes
    430 mm, 460 mm, 490 mm, 515 mm, 530 mm, 545 mm, 560 mm, 580 mm, 600 mm
  • Colours
    Xpeed Saturn Silver or Xpeed Red
  • Frame
    TorayCa T900 UD, TiCR™ cable routing, Italian BB, UCI approved
  • Forks and Shocks
  • Fork
  • Rear Shock
    N/A
  • eSystem
  • Motor
    N/A
  • Controller
    N/A
  • Display
    N/A
  • Battery Type
    N/A
  • Battery Integration
    N/A
  • Connectivity
    N/A
  • Charger
    N/A
  • Drivetrain and Brakes
  • Brake System
    Shimano Ultegra R8150, 2 pistons caliper (160mm / 140mm)
  • Rear Derailleur
    Shimano Ultegra RD-R8150 Di2 Rear Derailleur
  • Front Derailleur
    Shimano Ultegra FD-R8150 Di2 Front Derailleur
  • Shifters
    Shimano Ultegra Di2
  • Bottom Bracket
    Shimano Ultegra
  • Crankset
    Shimano Ultegra R8100 Chainset 50/34t
  • 170mm Crank length
    430mm, 460 mm, 490 mm, 515 mm, 530 mm frame sizes
  • 172.5mm Crank length
    530mm, 545 mm, 560 mm frame sizes
  • 175mm Crank length
    580 mm, 600 mm frame sizes
  • Cassette
    Shimano Ultegra CS-R8100 Cassette - 11-34t 12spd
  • Chain
    Shimano - 12 Speed
  • Cockpit
  • Handlebar
    MOST Talon Ultra Light
  • Stem
    Integrated
  • Grips
    MOST bar tape
  • Headset
  • Wheels
  • Wheelset
    MOST Ultrafast 45
  • Front Tyre
    Pirelli P7 Sport 35-622 black 60 tpi Nylon breaker
  • Rear Tyre
    Pirelli P7 Sport 35-622 black 60 tpi Nylon breaker
  • Max Tyre Clearance
  • Finishing Kit
  • Seatpost
    Pinarello Aero Seatpost
  • Saddle
    Pinarello Lynx Ultra Superflow
  • Pedals
    Not supplied: Shop pedals here
  • Extras
  • Kickstand
    N/A
  • Lighting
    N/A
  • Lock
    N/A
  • Carrier
    N/A
  • Mudguards
    N/A
  • Extras
    N/A
  • Please Note:
    Every effort has been made to ensure accuracy throughout this website. However, manufacturers reserves the right to change bike specifications, features, prices and colours without prior notice. If you would like to check the specification of a bike before purchasing, please call one of our stores.
Sizing Information

Size Guide

The choice of an exact frame size is a very complex and delicate topic which is not always straightforward without seeing an athlete on his/her bike. In addition to this, Pinarello offers a wide range of frame options and components that offer both very accurate position options but also require in-depth evaluations.

In addition to this, as more and more bikes are beginning to be fitted with an integrated handlebar and stem setup it is even more important to discuss sizing with us. Getting this measurement wrong can result in an incorrect position on the bike and an incur an expensive cost when having to replace the handlebar / stem combo for a correctly sized version.

If you have any questions specific to sizing, call our Cramlington store and speak with our bike fitter who will be able to help with an initial sizing before purchasing your bike. Once purchased we are happy to supply a full bike fit when you collect your new Pinarello from in store.

Get in touch with one of our stores (Newcastle - 0191 276 0941 or Cramlington - 01670 712 536) to find out how we can help.

Frame Geometry


430

460

490

515

530

545

560

580

600

ASeat Tube Length (mm)430460490515530545560580600
BSeat Tube Angle75.25°74.5°74°73.75°73.5°73.25°73°72.75°72.5°
CTop Tube Length (mm)492509525536545555565577590
DHead Tube Length (mm)123128140149159171185209230
EHead Tube Angle70°70.5°71°71.5°72°72.25°72.5°72.5°72.5°
FFork Rake (mm)525252474747474747
GTrail (mm)
HWheel Base (mm)
IChain Stay Length (mm)422422422422422422422422422
JBottom Bracket Drop (mm)677272727272726767
KStack (mm)527.5539.2552.4564.4575.8588.2602.4620.3640.4
LReach (mm)341.9352.1361.9368.5372.5376.7380.2384.1388.1
MStand Over Height (mm)
NHandlebar Width (mm)420420420420440440440460460
OStem Length (mm)809090100100100110110110
PCrank Length (mm)170170170170172.5172.5172.5175175
QWheel Size700c700c700c700c700c700c700c700c700c
Professional Opinion
  • Torayca T9000 UD
    The right balance between reactivity, dampening capabilities and lightness for competition.
  • Endurance+ Geometry
    Higher stack and a more compact reach, promoting a relaxed riding position that allows bike fitters to accurately fit all kinds of cyclists..
  • X-Stays
    A new Pinarello technology capable of absorbing vibrations maintaining a light weight frame and a very reactive BB stiffness.
  • Tyre Clearance
    35mm tires to unlock the frames’ true potential in terms of both comfort and speed.
