The Pinarello Dogma X Disc is a game-changer for riders who seek the perfect fusion of speed, endurance, and comfort.
The Pinarello Dogma X Disc is a game-changer for riders who seek the perfect fusion of speed, endurance, and comfort.
Pinarello

Pinarello Dogma X Disc - Dura-Ace equipped Endurance Bike - Xolar Blue

£13,300.00
Earn
in Customer Rewards when you buy this item today
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined
Earn Rewards
When you purchase this item, you will earn of rewards points to spend on your next purchase from us. You can spend your Rewards balance in-store & online.

Pinarello Dogma X Disc - Dura-Ace equipped Endurance Bike - Xolar Blue

Season:2025

Brand:Pinarello

Code:C1869271182-281-XB

The Pinarello Dogma X Disc is a game-changer for riders who seek the perfect fusion of speed, endurance, and comfort. Engineered with cutting-edge technology and precision craftsmanship, this high-performance road bike is designed to conquer long rides and demanding terrains with ease.

Advanced Carbon Frame for Maximum Comfort & Efficiency

Crafted from TorayCa T1100 1K Dream Carbon, the Dogma X Disc delivers an exceptional balance of stiffness, lightweight efficiency, and vibration absorption. Its innovative asymmetric frame design enhances power transfer, ensuring maximum responsiveness while maintaining all-day comfort for endurance-focused riders.

Shimano Dura-Ace Di2 12-Speed Groupset

Precision is at the core of the Dogma X Disc, featuring the Shimano Dura-Ace Di2 12-speed electronic groupset. With ultra-fast and seamless shifting, this state-of-the-art drivetrain guarantees smooth gear transitions and optimal performance across all riding conditions.

Princeton Grit 4540 Wheels & Pirelli P ZERO Race TLR Tires

Designed for ultimate speed and stability, the Dogma X Disc is equipped with Princeton Grit 4540 Wheels, delivering superior aerodynamics and responsiveness. Paired with Pirelli P ZERO Race TLR tires in a 700x35 size, this setup ensures exceptional grip, comfort, and efficiency on any road surface.

Striking Color Options

The Pinarello Dogma X Disc is available in four stunning Xolar-inspired finishes, each designed to turn heads:

  • Xolar Black – A sleek and timeless design that exudes power.
  • Xolar Blue – A vibrant, deep blue finish with an elegant touch.
  • Xolar Green< – A bold and striking shade, perfect for those who stand out.
  • Xolar Sun – A radiant, eye-catching color that embodies energy and speed.

Why Choose the Pinarello Dogma X Disc?

For riders who refuse to compromise on speed, comfort, and endurance, the Dogma X Disc is the ultimate choice. Whether you're tackling long-distance rides, rough road surfaces, or high-speed descents, this bike delivers an unparalleled riding experience with elite-level technology and race-ready performance.

Elevate your ride with the Pinarello Dogma X Disc – where endurance meets excellence.

Pinarello MyWay

Looking for something a bit different? Pinarello’s MyWay program allows riders to customize the Dogma F and Dogma X bikes with a personalized color scheme. Through a simple four-step process, cyclists can choose from five graphic layouts (mono, faded, cut, edge and xolar), 27 colours, five decal styles, and matte or glossy finishes, resulting in thousands of unique combinations.

Technical Information
  • Frame
  • Sizes
    430mm, 460 mm, 500 mm, 515mm, 530 mm, 540mm, 550 mm, 560mm, 575 mm, 595mm, 620 mm
  • Colours
    Xolar Black, Xolar Blue, Xolar Green or Xolar Sun
  • Frame
    TorayCa T1100 1K Dream Carbon with Nanoalloy technology, internal cable routing, Italian BB, UCI approved
  • Forks and Shocks
  • Fork
  • Rear Shock
    N/A
  • eSystem
  • Motor
    N/A
  • Controller
    N/A
  • Display
    N/A
  • Battery Type
    N/A
  • Battery Integration
    N/A
  • Connectivity
    N/A
  • Charger
    N/A
  • Drivetrain and Brakes
  • Brake System
    Dura Ace BR-R9200, 2 pistons caliper (160mm / 140mm)
  • Rear Derailleur
    Shimano Dura Ace Di2 RD-R9200 12s
  • Front Derailleur
    Shimano Dura Ace Di2 FD-9200 12S
  • Shifters
    Dura Ace BR-R9200
  • Bottom Bracket
    Shimano Dura Ace SM-BB9200
  • Crankset
    Shimano Dura Ace FC-R9200, HollowTech 2, 12s
  • 170mm Crank length
    430 mm, 460 mm, 500 mm, 515 mm frame sizes
  • 172.5mm Crank length
    530 mm, 540 mm, 550 mm, 560 mm frame sizes
  • 175mm Crank length
    575 mm, 595 mm, 620 mm frame sizes
  • Cassette
    Shimano Dura Ace CS-R9200 12S
  • Chain
    Shimano Dura Ace CN-HG 12S
  • Cockpit
  • Handlebar
    MOST Talon Ultrafast Light
  • Stem
    Integrated into handlebars
  • Grips
    MOST bar tape
  • Headset
  • Wheels
  • Wheelset
    PRINCETON GRIT 4540 DB
  • Front Tyre
    Pirelli P ZERO Race TLR 35-622
  • Rear Tyre
    Pirelli P ZERO Race TLR 35-622
  • Max Tyre Clearance
  • Finishing Kit
  • Seatpost
    Pinarello Aero seatpost with 3D printed titanium top seatclamp and bolts
  • Saddle
    Pinarello Lynx Ultra Superflow
  • Pedals
    Not supplied: Shop pedals here
  • Extras
  • Kickstand
    N/A
  • Lighting
    N/A
  • Lock
    N/A
  • Carrier
    N/A
  • Mudguards
    N/A
  • Extras
    N/A
  • Please Note:
    Every effort has been made to ensure accuracy throughout this website. However, manufacturers reserves the right to change bike specifications, features, prices and colours without prior notice. If you would like to check the specification of a bike before purchasing, please call one of our stores.
Sizing Information

Size Guide

The choice of an exact frame size is a very complex and delicate topic which is not always straightforward without seeing an athlete on his/her bike. In addition to this, Pinarello offers a wide range of frame options and components that offer both very accurate position options but also require in-depth evaluations.

In addition to this, as more and more bikes are beginning to be fitted with an integrated handlebar and stem setup it is even more important to discuss sizing with us. Getting this measurement wrong can result in an incorrect position on the bike and an incur an expensive cost when having to replace the handlebar / stem combo for a correctly sized version.

If you have any questions specific to sizing, call our Cramlington store and speak with our bike fitter who will be able to help with an initial sizing before purchasing your bike. Once purchased we are happy to supply a full bike fit when you collect your new Pinarello from in store.

Get in touch with one of our stores (Newcastle - 0191 276 0941 or Cramlington - 01670 712 536) to find out how we can help.

Frame Geometry


430

465

500

515

530

540

550

560

575

595

620

ASeat Tube Length (mm)

430

465

500

515

530

540

550

560

575

595

620

BSeat Tube Angle74.4°74.4°74°73.7°73.7°73.4°73.4°73°73°72.472°
CTop Tube Length (mm)505515525535545552557565575595620
DHead Tube Length (mm)107119124129138146157165178214254
EHead Tube Angle70°70°70.5°71°71.5°72°72°72.5°72.8°73°73°
FFork Rake (mm)4747474747474747474747
GTrail (mm)
HWheel Base (mm)
IChain Stay Length (mm)422422422422422422422422422422422
JBottom Bracket Drop (mm)7777777777777777777272
KStack (mm)966.8979.7986.8990.6997999.11004.31003.91011.71025.31047.6
LReach (mm)524.2535.5542.1548.6559568.4578.9588.4601.7632670.3
MStand Over Height (mm)
NHandlebar Width (mm)420420420420440440440460460460460
OStem Length (mm)809090100100100100110110110120
PCrank Length (mm)170170170170172.5172.5172.5172.5175175175
QWheel Size700c700c700c700c700c700c700c700c700c700c700c
Professional Opinion
  • Carbon T1100 1K
    High tensile and high modulus carbon fiber with patented Nanoalloy Technology for extreme performances.
  • Endurance Geometry
    A brand new approach that strikes the perfect balance between high-calibre performance and real-world comfort
  • X Stays
    TA new Pinarello technology capable of absorbing vibrations maintaining a light weight frame and a very reactive BB stiffness
  • Asymmetric Frame
    Pinarello understood that, while the thrust applied to both pedals is the same, the pull on the chain applies to the right side only. For this reason, all frames are optimized to compensate these unbalanced forces.
  • Tyre Clearance
    35mm tires to unlockthe frames’ true potential in terms of both comfort and speed.
