Sizes
Low Step: 46cm, 50cm, 54cm
Colours
Aqua / Black
Frame
Haibike, Aluminium 6061, Yamaha InTube 630, HD Interface, Aluminium 6061
Fork
SR Suntour, Mobie A32, Steel spring, 75 mm travel, Aluminium steerer tube 1 1/8, 15 x 100mm thru-axle
Rear Shock
N/A
Motor
Yamaha, PW-ST System, 250 Wh, 70 Nm, 25 km/h
Controller
N/A
Display
Yamaha, Multi Switch, 2.8 TFT, 16 functions
Battery Type
Yamaha, InTube, 630 Wh
Battery Integration
Internal
Conectivity
N/A
Charger
N/A
Brake System
Shimano, MT410, Hydraulic disc brakes / Shimano, RT30-M, (180 mm / 180 mm)
Rear Derailleur
Shimano, Deore M5100
Front Derailleur
N/A
Shifters
Shimano, Deore M5100, Trigger switch
Bottom Bracket
Integrated into motor
Crankset
Haibike, Forged, Aluminium
Cassette
Shimano CS-HG400, 11-45T
Chain
KMC, e11S
Handlebar
Ergoriser, oversize, 720 mm
Stem
aluminium, angle ajustable, A-head, 31.8 mm
Grips
XLC, Comfort bo3
Headset
Front Hub
Shimano, MT400, Centerlock
Rear Hub
Shimano, Shimano Acera T3000
Rims
Schürmann, Yak25, With Eyelets, Double Wall, Aluminium
Front Tyre
WTB, Groov-E, 61-584, 27.5 x 2.4 inch
Rear Tyre
WTB, Groov-E, 61-584, 27.5 x 2.4 inch
Max Tyre Clearance
Seatpost
XLC, Aluminium, Patent, 31.6 mm
Saddle
XLC, Trekking
Pedals
VP, E461, Aluminium, with Reflector
Kickstand
Ursus, Mooi, Rear stand
Lighting
Haibike, Skybeamer 150, 50 lm / AXA, Juno Ebike
Lock
N/A
Carrier
Racktime, Tria
Mudguards
Eurofender Chromoplastics
Other
N/A
Please Note:
Every effort has been made to ensure accuracy throughout this website. However, manufacturers reserves the right to change bike specifications, features, prices and colours without prior notice. If you would like to check the specification of a bike before purchasing, please call one of our stores.
